DO200 Smart
Parking Occupancy Sensor
The DO200 parking occupancy sensor is designed to monitor if the parking space is occupied or not. It combines ultrasonic and magnetic technology to achieve high accuracy.
Data is sent to cloud server through built-in wireless module (NB-IoT, LoRaWAN, Sigfox), user can monitor the parking spaces conveniently.
Features
Parking space occupancy monitoring
IP68 waterproof
Easy Installation & Integration
Ultrasonic+Magnetic Technology
Low power consumption
Accurate Measurement
Network Diagram
With wireless module, it upload data to application server. Finally user can monitor the status remotely.
It is applicable for smart parking application, parking bay booking and etc.
SAAS
Specification
Dimension : 115*115*50mm
Net Weight : 150g
Color : Black
Shell Material : ABS
Principle : Ultrasonic + Magnetic
Accuracy : 99%
Ultrasonic precision : 3mm
Range : <120cm
Communication ： NB-loT/LoRaWAN/Sigfox
Frequency :
NB-IoT: B3/B5/B8/B20/B28
LoRaWAN: CN470/EU868/AU915 /US915/AS923
Sigfox: RCZ1, RCZ2, RCZ3, RCZ4
Sim Card Socket Size : Mirco
Internal Battery : Non-recharged Lithium battery 8000mah@3.6VDC
Lifetime : 3 years at 6 times report per day
Operating Temperature : -20 ~+70℃
Storage Temperature : -40 ~ +85℃
Protection Level :
IP67
Installation
(1) The sensor should be installed 1/3 of the entrance and exit, not the center of the parking space or near the non-entrance site.
(2) The sensor should be installed at a distance of more than 1m from the adjacent parking space. Below this distance, excessive interference from neighboring vehicles will result in
Drill holes in the ground and place the sensor so that the surface of the sensor is1 cm below the surface of the parking space. Use expansion screws to fix the equipment. After installation, fill the space around the equipment. Note: Do not cover the ultrasonic probe of DO200 sensor, otherwise the ultrasonic measurement will be affected.
